Galvanized Round Hole Perforated Sheet

Galvanized round hole perforated sheet is made of hot-dipped galvanized sheet or electric galvanized sheet.It's an extremely cost-effective solution for corrosion protection. A layer of metallic zinc is coated on the steel sheet surface to prevent steel sheet surface from being corroded and prolong service life.which effectively blocks corrosive elements such as atmosphere and moisture. This is one of the common means of corrosion prevention in the metal industry.It is widely used in the architecture, light industries, automobile and other industries.YILIDA can provide material with different zinc coating, the hot selling zinc coating is 40g, 80g, 120g, G90 (275g).

Inquire Now

The punching process starts with accurate mold design. We believe that the quality of the mold determines the quality of the product to a large extent. Therefore, in recent years, YILIDA has invested a lot of money in this field, which has significantly improved our mold making ability. Our factory now has thousands of sets of punching dies to meet the requirements of our customers.

After punching, there may be deformation. Therefore, we can restore the deformed perforated plate to its original flat state by using the leveling machine.

Features:

Durable and lasts a long time

High strength

Corrosion-resistant

Economical

Wide range of applications

Specification

Round, in 60°staggered rows
Code	Hole Dia (R)-mm	Pitch(T)-mm	Open Area%
R0.8T2	0.8	2	14.6
R1T2	1	2	22.8
R1.2T2.5	1.2	2.5	21
R1.5T3	1.5	3	22.8
R2T3	2	3	40.4
R2T3.5	2	3.5	30
R3T5	3	5	33
R4T6	4	6	40.4
R5T8	5	8	35
R6T9	6	9	40
R8T11	8	11	48.1
R10T13	10	13	53.8
R10T15	10	15	40.4
R20T27	20	27	49.9

Round, in 45°staggered rows
Code	Hole Dia (R)-mm	Pitch(T)-mm	Open Area%
R2T6	2	6	17.4
R3T8	3	8	22.1
R4T8	4	8	39.3
R5T9	5	9	48.5
R6T10	6	10	56.5
R7T14	7	14	39.3
R8T18	8	18	31
R12T28	12	28	28.8
R15T40	15	40	22.1
R16T40	16	40	25.1
R26T50	26	50	42.5

Round, in straight rows
Code	Hole Dia (R)-mm	Pitch(T)-mm	Open Area%
R2T4	2	4	19.6
R3T6	3	6	19.6
R4T8	4	8	19.6
R5T8	5	8	30.7
R8T12	8	12	39.4
R12T15	12	15	50.2
R15T20	15	20	44.2
R20T30	20	30	34.9
R30T50	30	50	28.3
